PHOSPHATE COATING SERVICES
Phosphate coating improves corrosion resistance and primer and topcoat adhesion, extending the service life of parts and components. Contact us to discuss your project and request a quote.
PHOSPHATE COATING OVERVIEW
What Is Phosphate Conversion Coating & How Does It Work?
Phosphate Coating is a chemical surface treatment process (often applied after sandblasting) that involves a chemical reaction between a metal surface and a phosphate solution, creating a thin, crystalline layer that bonds to the substrate. In addition to improving corrosion resistance, the crystalline layer accentuates surface topography, enhancing the mechanical bond to protective coatings.
Where Is Phosphate Coating Used?
Phosphate coating is commonly specified as a pre-treatment for Moly Coating, Teflon Coating, and Industrial Painting systems on fasteners, valves, and machined components where maximum coating adhesion is critical, particularly in high-load, high-wear, or chemically aggressive service environments.
Which Substrate Materials Can Be Phosphate-Coated?
CCI specializes in zinc phosphate coating, which has a wide range of applications and works well on many ferrous substrates (carbon steel, cast iron, & more) and some non-ferrous substrates (zinc, aluminum).
BENEFITS OF ZINC PHOSPHATE COATING
Three main types of phosphate coatings are zinc, manganese, and iron. Custom Coatings International specializes in zinc phosphate coating, regarded as the “workhorse” among phosphate treatments. It offers superior corrosion resistance and paint durability compared to other options. Below are the key benefits of zinc phosphate.
-
Superior Corrosion Resistance
Forms a dense, crystalline structure that provides excellent barrier protection.
Performs especially well when combined with paint, powder coat, or oil post-treatment.
Outperforms iron phosphate significantly in salt spray/humidity tests.
-
Excellent Paint/Coating Adhesion
Creates a rough, crystalline surface that dramatically improves the adhesion for paints and powder coatings.
Reduces underfilm creep if corrosion starts at a scratch or edge.
-
Versatile Application Range
Works on many ferrous substrates (carbon steel, cast iron) and some non-ferrous (zinc, aluminum).
Suitable for both decorative (pre-paint) and functional (wear/corrosion) purposes.
-
Balanced Performance
Compared to manganese phosphate (which is better for wear), zinc phosphate offers a better blend of corrosion resistance + adhesion rather than just lubricity, making it one of the most versatile phosphate coatings.
PHOSPHATE COATING INDUSTRY APPLICATIONS

Oil & Gas
Oil and gas completion equipment (tubing, couplings, downhole tools), Valves, pumps, and flanges are exposed to corrosive environments.
Fasteners & Hardware
Bolts, nuts, screws, and threaded parts where both corrosion resistance and paint adhesion are required.
Industrial Equipment
Heavy machinery, agricultural equipment, construction equipment, and parts are exposed to moisture and wear.
Automotive
Pretreatment for car bodies prior to painting (improved corrosion protection), Engine components, fasteners, and brackets.
Aerospace & Defence
Aircraft structural steel components requiring corrosion resistance.
Credentials
- ISO 9001-certified, ISN member contractor, and COR-certified
- NACE Level 1 & 2 Certified Coating Inspectors on staff, with NACE Level 3 Certified Coating Inspectors available upon request
Quality Assurance & Control
- Surface preparation to SSPC/NACE standards, with profile measured and recorded per specification
- Climate-controlled blast and coating bays for proper application and cure
- QC testing, including ambient condition monitoring and DFT readings provided in every project
- X-cut adhesion, compressed air (blotter), dust, and soluble salt testing, and holiday testing available upon request
- Inspection and Test Plans (ITPs) and QC documentation available upon request
WHY CHOOSE CUSTOM COATINGS INTERNATIONAL?
CCI has invested significant resources in building and strengthening our quality assurance and control department, training our team to ensure every project meets specifications.
REQUEST A QUOTE
To initiate the quoting process, please provide the following information (if available):
• Drawings or isometrics
• Coating specifications
• Operating environment details (temperature range and chemical exposure)
• Project timeline or required completion date
We look forward to working with you on finding the right protective coating for your project. If you have any questions, please contact us using the links below.
Info@ccintl.ca for general inquiries
sales.support@ccintl.ca for quote requests
ZINC PHOSPHATE COATINGS FAQS
-
Our zinc phosphate bath has a tray size of 4 feet in length and 1.5 in width, allowing us to work with a variety of different parts and components of different sizes.
-
Zinc phosphate is a type of conversion coating that’s applied to variety of compatible metals to improve corrosion resistance and adhesion for paint. It’s one of the most widely used phosphate coatings in industry, especially in automotive, appliances, and construction steel.
-
You can zinc phosphate without abrasive blasting first, but it is not recommended if the intention for the metal is for coating adhesion. Sandblasting/ abrasive blasting is premier option in surface pre-treatment and phosphating is an additional treatment on top to better ensure adhesion of paints and coatings.
-
In our shop in Leduc, Alberta, Canada, we receive numerous amounts of zinc phosphating jobs, with common paint coats being Molybdenum Disulfide Coatings, polymer Teflon coatings, Industrial paint coatings, and powder coatings.
